Select a module below to follow the gas path

Aircraft engineering, taken apart.

Open courses, study notes and live 3D drawings for engineers, technicians and students of flight.

Two-spool turbofan
01

Aerospace engineering

Eighteen degree-level subjects in five disciplines, each built on a standard textbook and linked to the licence modules it supports.

01

Aerodynamics & Flight

4 subjects · Intermediate to Advanced
Lift, drag, the finite wing, performance, stability and control, rotorcraft.
Wing in the tunnel, live
02

Propulsion

3 subjects · Foundation to Advanced
Gas turbines, propulsion theory, piston engines and propellers.
Boxer engine, live
03

Structures & Systems

3 subjects · Intermediate
Airframe structures, aircraft systems, avionics.
High-lift system, live
04

Design & Operations

4 subjects · Foundation to Advanced
Aircraft design, unmanned aircraft, human factors, regulations.
MALE UAS in orbit, live
05

Foundations

4 subjects · Foundation
Mathematics, thermodynamics, fluid mechanics, materials.
02

Pitch the aerofoil

Potential flow around a Joukowski aerofoil with the Kutta condition. Move the cursor up and down over the tunnel to change the angle of attack.

Angle of attack0
Lift coefficient0
Circulation Γ/U c0

CL = 2Γ / (U c)    Γ = 4πUR sin(α − θTE)

The circulation is fixed by the requirement that the flow leaves the sharp trailing edge smoothly. Read the full derivation in the note on thin-aerofoil theory.

03

Aerodynamics, in fourteen lectures

A video series built on 3D scenes of the A320, from the atmosphere to lateral-directional stability. Each lecture comes with a written note.

05

Licence training

The eighteen basic-knowledge modules of EASA Part-66, Appendix I.

ModuleTitleCategories
M1MathematicsA · B1 · B2 · B2L · B3
M2PhysicsA · B1 · B2 · B2L · B3
M3Electrical FundamentalsA · B1 · B2 · B2L · B3
M4Electronic FundamentalsB1 · B2 · B2L · B3
M5Digital Techniques / Electronic Instrument SystemsA · B1 · B2 · B2L · B3
M6Materials and HardwareA · B1 · B2 · B2L · B3
M7Maintenance PracticesA · B1 · B2 · B2L · B3
M8Basic AerodynamicsA · B1 · B2 · B2L · B3
M9Human FactorsA · B1 · B2 · B2L · B3
M10Aviation LegislationA · B1 · B2 · B2L · B3
M11Aeroplane Aerodynamics, Structures and SystemsA1 · A2 · B1.1 · B1.2 · B1.E · B3
M12Helicopter Aerodynamics, Structures and SystemsA3 · A4 · B1.3 · B1.4
M13Aircraft Aerodynamics, Structures and SystemsB2 · B2L
M14PropulsionB2 · B2L
M15Gas Turbine EngineA1 · A3 · B1.1 · B1.3
M16Piston EngineA2 · A4 · B1.2 · B1.4 · B3
M17PropellerA1 · A2 · B1.1 · B1.2 · B1.E · B3
M18Electric Power PlantB1.E
